| Valve function | 5/2 monostable |
| Actuation type | Electrical |
| Valve size [mm] | 14 |
| Normal nominal flow [l/min] | 700 to 780 |
| Operating pressure [bar] | 2.5 to 8 |
| Construction set up | Piston pusher |
| Reset mode | Pneumatic spring |
| Permission | RCM mark c CSA us (OL) c UL us - Recognized (OL) |
| Protection category | IP40 IP65 With Socket |
| Nominal width [mm] | 5,6 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Hand assist actuation | Ratcheting Covered tentative |
| Control type | pilot operated |
| Control air supply | Internal |
| Überdeckung | positive Überdeckung |
| Control pressure [bar] | 2.5 to 8 |
| Vacuum capable | no |
| Shifting time off [ms] | 22 |
| Shifting time on [ms] | 14 |
| Power-on time | 100 % |
| Max. positive test impulse at 0 signal [Mikrosekun] | 700 |
| Max. negative test impulse for 1 signal [Mikrosekun] | 900 |
| Coil characteristic value | 24 V DC: Low current phase 0.3 W, high current phase 1,0 W 24 V DC: 1 W |
| Permitted voltage oscillations | ± 10 % |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Oscillation strength | Transport use test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Limits ambient and media temperature | -5 - 50 °C Without holding current reduction |
| Shock resistance | Shock test with degree of severity 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Medium temperature [°C] | -5 to 60 |
| ambient temperature [°C] | -5 to 60 |
| Product weight [g] | 78 |
| electrical connection: | Via electrical connection plate |
| Fastening type | With throughway bores Selectively: on terminal strip |
| Pneumatic connection 1 | G1/8 |
| Pneumatic connection 2 | G1/8 |
| Pneumatic connection 3 | G1/8 |
| Pneumatic connection 4 | G1/8 |
| Pneumatic connection 5 | G1/8 |
| Material information | RoHs compliant |
| Seals material | HNBR NBR |
| Housing material | Aluminium wrought alloy |
