VitalMRO is Authorized Distributor for This Product.
| Stroke [mm] | 50 |
| Piston diameter | 50 mm |
| Piston rod thread | M16x1,5 |
| Dampening | P: Elastic silencer rings / plates double-sided |
| installation position | arbitrary |
| Construction set up | Piston piston rod cylinder tube |
| Position detection | For proximity switch |
| Operating pressure [bar] | 1 to 10 |
| Principle of operation | double acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| ambient temperature [°C] | -20 to 80 |
| Theoretical force at 6 bar, Return flow [N] | 989,6 |
| Fastening type | With Accessories |
| Pneumatic connection | G1/4 |
| Material information | RoHs compliant |
| Cover material | Aluminium wrought alloy |
| Seals material | NBR TPE-U(PU) |
| Piston rod material | High-alloyed steel |
| Cylinder tube material | High-alloyed stainless steels |
| Theoretical force at 6 bar, flow [N] | 1.178,1 |
| Moving mass [g] | 538 |
| Product weight [g] | 1.287 |
| Weight | 1,3 kg / Pcs |
| GTIN | 4052568158538 |
| Customs duty number | 84123100 |
| RoHS compliant | Yes |
| Manufacturer | Festo |
