| Packing size | 1 |
| Corrosion resistant class KBK | 2 - moderate corrosion stress |
| Food compatibility | See expanded material information |
| ambient temperature [°C] | -25 to 70 |
| Maritime classification | see Certificate |
| Product weight [g] | 36 |
| Material information | LABS containing materials included RoHs compliant |
| installation position | arbitrary |
| Nominal width [mm] | 19,20 |
| Construction set up | Push-pull principle |
| Operating pressure complete temperature range [bar] | -0.95 to 7 |
| Temperature depending operating pressure [bar] | -0.95 to 15 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Pneumatic connection 1 | For tube / hose exterior diameter 22 mm |
| Pneumatic connection 2 | für Rohr oder Schlauch mit Außendurchmesser 22 mm |
| Housing material | POM |
| Sleeve material | POM |
| Hose clamping segment material | High-alloyed stainless steels |
| Weight | 36 g / Pcs |
| GTIN | 4052568038472 |
| Customs duty number | 39174000 |
| RoHS compliant | Yes |
| Manufacturer | Festo |
