| size | Maxi |
| Model series | D |
| Actuation fuse | Rotary button with stopper |
| installation position | arbitrary |
| Construction set up | Pre-controlled piston control valve |
| Controller function | Output pressure constant With relieving |
| pressure display | with pressure gauge |
| Operating pressure [bar] | 0 to 16 |
| Pressure regulation range [bar] | 0.5 to 12 |
| Max. pressure hysteresis [bar] | 0,4 |
| Normal nominal flow [l/min] | 10.500 |
| Maritime classification | see Certificate |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Air purity class at the output | Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases |
| Medium temperature [°C] | -10 to 60 |
| ambient temperature [°C] | -10 to 60 |
| Product weight [g] | 1.200 |
| Fastening type | Front panel integration pipe installation With Accessories |
| Pneumatic connection 1 | G1/2 |
| Pneumatic connection 2 | G1/2 |
| Material information | RoHs compliant |
| Connection plate material | Zinc pressure cast |
| Seals material | NBR |
| Housing material | Zinc pressure cast |
