VitalMRO is Authorized Distributor for This Product.
| Valve function | 3/2 open/closed monostable |
| Actuation type | pneumatic |
| Build.width [mm] | 26,0 |
| Normal nominal flow [l/min] | 500 |
| Operating pressure [bar] | -0.95 to 10 |
| Construction set up | Plate seat |
| Reset mode | Mechanical spring |
| Nominal width [mm] | 5 |
| Exhaust function | Can be throttled |
| Sealing principle | Soft |
| installation position | arbitrary |
| Control type | Direct |
| Control air supply | external |
| Flow direction | Reversible |
| Überdeckung | negative Überdeckung |
| Control pressure [bar] | 1 to 10 |
| Shifting time off [ms] | 10 |
| Shifting time on [ms] | 4 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Corrosion resistant class KBK | 1 - low corrosion stress |
| Bearing temperature [°C] | -20 to 60 |
| Medium temperature [°C] | -10 to 60 |
| control medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| ambient temperature [°C] | -10 to 60 |
| Product weight [g] | 150 |
| Fastening type | With throughway bores Selectively: on terminal strip |
| Control air 110 connection | G1/8 |
| Control air 12 connection | G1/8 |
| Pneumatic connection 1 | G1/8 |
| Pneumatic connection 11 | G1/8 |
| Pneumatic connection 2 | G1/8 |
| Pneumatic connection 3 | G1/8 |
| Pneumatic connection 33 | G1/8 |
| Material information | RoHs compliant |
| Seals material | NBR |
| Housing material | Aluminium die casting |
| Pitch dimension [mm] | 27 |
| Max. switching frequency [hz] | 12 |
