VitalMRO is Authorized Distributor for This Product.
| Valve function | OR function |
| Pneumatic connection 1 | G1/4 |
| Pneumatic connection 2 | G1/4 |
| Fastening type | With throughway bores |
| Normal nominal flow [l/min] | 1.170 |
| Operating pressure [bar] | 1 to 10 |
| ambient temperature [°C] | -10 to 60 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Nominal width [mm] | 6,5 |
| Information about operating and control medium | Oiled operation possible (required in further operations) |
| Medium temperature [°C] | -10 to 60 |
| Pneumatic connection 3 | G1/4 |
| Material information | RoHs compliant |
| Housing material | Aluminium wrought alloy |
| installation position | arbitrary |
| Product weight [g] | 110 |
| Seals material | NBR |
| Weight | 110 g / Pcs |
| GTIN | 4052568001308 |
| Customs duty number | 84812090 |
| RoHS compliant | Yes |
| Manufacturer | Festo |
