| installation position | arbitrary |
| Min. tightening time [ms] | 10 |
| Power-on time | 100% |
| Coil characteristic value | 42 V AC: 50/60 Hz, pull-in power 9 VA, holding power 7 VA 24 V DC: 4,5 W |
| Permitted voltage oscillations | ± 10 % |
| Protection category | IP65 |
| ambient temperature [°C] | -5 to 40 |
| Product weight [g] | 55 |
| electrical connection: | 3 pin plug flag for MSSD-F |
| Fastening type | With Knurled nut |
| Material information | RoHs compliant |
| Winding material | Copper |
| Performance factor cos {phi} | 0.7 |
| Switching position display | no |
| Permitted frequency oscillations | ± 5 % |
| Max. tightening torque Socket [Nm] | 0,4 |
| Solenoid material | Duroplast Copper Steel |
| Weight | 55 g / Pcs |
| GTIN | 4052568007911 |
| Customs duty number | 85059029 |
| RoHS compliant | Yes |
| Manufacturer | Festo |
